Product Introduction
Suitable for multiple industrial water treatment scenarios, automatic cleaning operation, stable running, widely applied in EPC water engineering projects.
Features
The Automatic Self Cleaning Filter is an intelligent filtration solution designed for continuous removal of suspended solids, particles, and mechanical impurities from water systems.
By combining advanced filtration technology with automatic cleaning control, the filter can continuously operate while automatically removing accumulated contaminants from the filter screen without manual intervention or system shutdown.
Designed for industrial and commercial water treatment applications, the self cleaning filter provides efficient filtration, stable operation, and reduced maintenance requirements. It is widely applied as a pre-filtration unit or process filtration equipment in industrial water systems, municipal projects, irrigation systems, cooling water circulation, and other applications requiring reliable and automatic filtration.
1. Automatic Self Cleaning Technology
The filter integrates differential pressure monitoring and automatic control technology to detect filter contamination and initiate the cleaning process automatically.
The cleaning cycle is controlled according to actual operating conditions, ensuring efficient removal of impurities while reducing unnecessary water consumption.
2. Continuous Filtration Operation
The self cleaning filter is designed to clean itself during operation without interrupting the water supply.
This continuous filtration capability improves system reliability and is especially suitable for applications requiring uninterrupted water treatment processes.
3. High-Efficiency Solid Removal
The precision-engineered filter screen effectively captures suspended solids, sediment, rust, and other mechanical impurities.
Different filtration ratings and screen materials can be selected based on raw water characteristics and process requirements.
4. Intelligent Control System
Equipped with an automatic control system, pressure sensors, and electric or hydraulic valves, the filter enables fully automatic operation with minimal human intervention.
The control parameters can be adjusted according to different project conditions.
5. Robust Structure and Long Service Life
The filter body is manufactured with durable materials suitable for various industrial environments.
The optimized structure ensures low pressure loss, stable performance, and reliable operation under continuous working conditions.
6. Flexible Configuration Options
The equipment can be customized according to:
Water quality conditions
Reduce Operation and Maintenance Costs
Compared with traditional filtration equipment requiring frequent manual cleaning or replacement of filter elements, the automatic self cleaning filter reduces labor requirements and maintenance frequency.
Automatic monitoring and cleaning ensure stable filtration performance and prevent excessive pressure loss caused by accumulated contaminants.
The filter provides effective removal of suspended solids, protecting downstream equipment and improving the overall performance of water treatment systems.
With multiple material options and customizable configurations, the filter can be adapted to different applications, including clean water, industrial process water, and challenging water environments.
The compact design and automatic control features allow simple installation and integration into existing or new water treatment systems.
It can be used as a standalone filtration unit or as part of complete water treatment solutions provided by professional system integrators.
Industrial Water Treatment
Used for removing suspended solids and protecting downstream equipment in industrial process water systems, production water systems, and circulating water systems.
RO / NF / UF Pretreatment
Installed before membrane filtration systems to reduce suspended solids loading, protect membrane components, and improve system stability.
Cooling Water Circulation
Helps maintain clean circulating water quality, reduce fouling risks, and improve heat exchange system efficiency.
Municipal Water Supply
Applied for primary filtration and pipeline protection in municipal water treatment and water distribution systems.
| Technical Parameters | |
| Parameter | Specification |
| Single unit flow rate | 25~2800t/h, larger flow rate can be achieved by multiple units in parallel |
| Minimum working pressure | 0.2MPa |
| Maximum working pressure | 0.6MPa/1.0MPa/1.6MPa/2.5MPa/4.0MPa |
| Maximum working temperature | 70°C |
| Filtration precision | 80-5000 microns |
| Control mode | Differential pressure, time and manual |
| Cleaning time | 60 seconds |
| Cleaning pressure drop | 0.01~0.03MPa |
| Control voltage | AC 220V |
| Rated operating voltage | Three-phase, 220V, 380V, 50HZ |
| Specification Model and Parameters | |||||||
| Model | Pipe Diameter (mm) | Filtration Flow Rate (t/h) | Filtration Area (cm2) | Drain Valve DN (mm) | Water Consumption per Cleaning (Kg) | Motor Power (KW) | Weight (Kg) |
| DST12 | DN300 | 650 | 9500 | DN50 | 200 | 0.37 | 320 |
| DST14 | DN350 | 900 | 12000 | DN50 | 350 | 0.55 | 480 |
| DST16 | DN400 | 1200 | 12000 | DN50 | 350 | 0.55 | 520 |
| DST18 | DN450 | 1500 | 15000 | DN65 | 350 | 0.75 | 835 |
| DST20 | DN500 | 2000 | 15000 | DN65 | 350 | 0.75 | 900 |
| DST24 | DN600 | 2800 | 18000 | DN65 | 350 | 0.75 | 1080 |
Smart Filtration Systems, Efficient Integrated Solutions
